TECHNICAL SPECIFICATION:

Ozone Output

0.26 g/h at 1.5 L/min dry air ;

0.1 g/h at 1.5 L/min normal air

Ozone Concentration

> 4.0 mg/L at 0.5-1.0 L/min gas flow

Gas Flow

1.4 L/min recommended

Output Connection

OD 5.0 mm

Continuous operation

24 h/day with cooling system

Ozone generating method

Corona discharge

Input voltage

110/220V AC

Power input

< 6 W

Operating temperature

-10 °C~ +60 °C

Storage temperature

-20 °C~ +70 °C

Size Generator L x W x H (mm)

73.6 x 40 x 30

Size Electronic L x W x H (mm)

100 x 35 x 26 potted

Weight

0.17 kgs

Able to be used

water or air treatment
