TECHNICAL SPECIFICATION:

Ozone Output

700 mg/H with air source of 8L/min,

RH 20%, 25℃

Ozone Concentration

> 5.0 mg/L at1.0 L/min gas flow

Gas Flow

8.0 L/min recommended

Output Connection

OD 5.0 mm

Continuous operation

24 h/day with cooling system

Ozone generating method

Co rona discharge

Input voltage

100-240VAC, 50-60Hz

Power input

< 12W

Operating temperature

-10 °C~ +60 °C

Storage temperature

-20 °C~ +70 °C

Size Generator L x W x H (mm)

145.6 x 40 x 30 mm

Size Electronic L x W x H (mm)

124 x 100 x 36 mm

Weight

0.5 kgs

Able to be used

water or air treatment
