TECHNICAL SPECIFICATION:

Ozone Output

 2000 mg/H with air source of 10L/min, RH 15%, 20℃

Ozone Concentration

> 5.0 mg/L at1.0 L/min gas flow

Gas Flow

6.0 L/min recommended

Output Connection

OD 5.0 mm

Continuous operation

24 h/day with cooling system

Ozone generating method

Corona discharge

Input voltage

With quartz tube /stainless steel electrode

110/220V AC

Power input

< 35W

Operating temperature

-10 °C~ +60 °C

Storage temperature

-20 °C~ +70 °C

Size Generator L x W x H (mm)

148 x 40 x 40 mm

Size Electronic L x W x H (mm)

113 x 48.3 x 31.2 mm

Weight

0.75 kgs

Able to be used

water or air treatment
